Power	100W
Material	Die-cast Aluminum
LED Chip	Luxeon 3030
Light Efficiency	>100lm/W
CCT:	3000-6500k
Viewing Angle：	120°
IP	65
Working Environment:	30℃~+70℃

Module	150W*2
Encapsulation	Glass/EVA/Cells/EVA/TPT
Efficiency of solar cells	18%
Tolerance	±3%
Voltage at max power(VMP)	18V
Current at max power(IMP)	8.43A
Open circuit voltage(VOC)	22V
Short circuit current(ISC)	8.85A
Diodes	1by-pass
Protection Class	IP65
Operate temp.scope	-40/+70℃
Relative humidity	0 to 1005

Rated Voltage	12V
Rated Capacity	90 Ah*2pcs
Approximate Weight(kg,±3%)	26.6KG*2pcs
Terminal	Cable（2.5mm²×2 m）
Maximum Charge Current	10 A
Ambient Temperature	-35~55 ℃
Dimension	Length (mm,±3%)	329mm
	Width (mm,±3%)	172mm
	Height (mm,±3%)	214mm
Case	ABS

Rated working voltage

15A DC24V
